Custom Enclosures Suspension System
Safe/Vue® Custom Enclosures
are the perfect solution for controlling ultraviolet rays, noise, dust or sparks.


Individual strips allow easy access at any point throughout the enclosure.

A variety of colors and thicknesses are available in semi-transparent PVC which allows supervisors to monitor the activity and the safety of the worker inside the enclosure.
Floor Mounted Suspension System

BASE 6"X6"

BASE 12"X12"

COLUMN 1 1/4" SQUARE TUBE

HORIZONTAL CROSS MEMBER
base 6"x6"
base 12"x12"
column 1 1/4" square tube
horizontal cross member

THREE WAY CONNECTOR 90

SPLICE CONNECTOR

SPLICE CONNECTOR RIGHT

SPLICE CONNECTOR LEFT
three way cross member
splice connector
splice connector right
splice connector left

All Suspension System components are zinc plated, except as noted. Factory recommends base plates be attached to floor for safety and stability and 12" x 12" base for column heights over 6'. Maximum single span is 8'.

Custom Enclosures

  • 8" x .080, 12" x .120, or 48" x .080 PVC Strips.

  • PVC strips listed are available in bulk roll form. See ClearFlex II® or consult your Aleco sales representative.
Colors available for general applications:
clear

Clear

 ambertech

Ambertech
blue

Blue

 black

Black
green

Green




Colors available for welding applications:
dark amber

Dark Amber

aztec orange

Aztec Orange



The patented MAXBULLET® SYSTEM exclusively from ALECO® significantly reduces initial installation time by as much as 75% and replacement strip times by as much as 90%.

Strips snap on and off without the needs for tools, yet remain firmly locked onto the bullet-shaped studs.
